HP Data Protector software is automated backup and recovery software for single-server to enterprise environments, supporting disk storage or tape storage targets. It provides cross-platform, online backup of data for Microsoft Windows, Unix, and Linux operating systems.

For business- and mission-critical applications, HP Data Protector Zero Downtime Backup leverages array-based solutions to offload processing from the server and perform backup operations on a copy of the production data. HP Data Protector Instant Recovery retrieves data from the replicated images on disk for recovery to specific points in time.^[1]

HP Data Protector originated as OmniBack. The last version to use the OmniBack name was version 4.1, which was retired in 2004.^[2]

History[edit]

When Hewlett-Packard acquired Apollo Computer in 1989, the latter had already developed a backup system entitled the 'OmniBack Network Backup System,' which was available on the market at the time.^[3] HP continued^[4] to develop this product under the 'OmniBack' name for the purpose of backing up individual files and raw disk partitions. A related but distinct product 'OmniBack/Turbo' was developed for backing up databases.^[5]

In 1996 HP released OmniBack II 2.0 and merged OmniBack II and OmniBack/Turbo into a single product, although it was still impossible to create a single job which would contain a database and a file system backup. A Windows NT port was released with version 2.3.^[6] Version 2.55 was released in 1997 and included support for HP-UX and IBM AIX.^[7]

In the interim, Hewlett-Packard withdrew development from Slovenia through to Germany. Significant time was spent delivering version 3.5.2 for Solaris. Once complete however, this allowed quick ports through to Tru64 and Linux.

With version 5.0, the OmniBack name was dropped. Since then, the product has been called HP Openview Storage Data Protector and HP StorageWorks Data Protector.^[8] The product is now called HP Data Protector software.

HP announced the release of HP Data Protector 9.0 (as a part of its Adaptive Backup & Recovery initiative) in May 2014, and released it in July 2014. It was released in July 2014 along with two companion products: HP Data Protector Management Pack and HP Backup Navigator.^[9]

Architecture[edit]

The HP Data Protector architecture is based on the concept of a cell: a network environment that contains a Cell Manager, clients, and backup devices. The Cell Manager is the main system that centrally controls and manages the cell. It contains a database, runs the core software, and runs the backup and restore sessions, writing session information to the database.

A client can be any system within the cell. Clients that are to be backed up require the installation of a Disk Agent. Clients that control the backup and restore data require the installation of a Media Agent.^[10]

For multi-site operations, the Data Protector Manager of Managers (MoM) allows local administrators to control data backup and restore, but providing centralizedenterprise monitoring and media management. In this configuration, multiple Data Protector cells are grouped, configured and managed from the MoM.^[11]

Data deduplication[edit]

HP Data Protector offers data deduplication capabilities with the ability to compare blocks of data being written to a backup device with data blocks previously stored on the device. For data deduplication, HP Data Protector allows any disk-based data storage to be the target storage. Tape drives cannot be used as deduplication targets because of their sequential nature opposed to the block-oriented nature of disk-devices.^[12]

Virtual server protection[edit]

HP Data Protector supports backup and restore of virtual servers, including protection for the whole Virtual machine and its application data.^[13] Supported virtual environments include VMware, Windows 2008 Hyper-V (Limited), Microsoft Virtual Server 2005 and HP Integrity Virtual Machines.^[14] Citrix XenServer support is no longer officially provided.

Centralization encryption[edit]

HP Data Protector includes automated key management for software and Linear Tape-Open LTO-4 Encryption. Users have the choice of client-based encryption for data security, or they can use the encryption functionality in LTO-4 (and later generation) tape drives.^[15]

Hp Data Protector 9 Patches Download

Data Protector Notebook Extension[edit]

In November 2009, HP began offering HP Data Protector Notebook Extension.^[16] HP Data Protector Notebook Extension enables users to back up and recover data while working remotely and offline. With HP Data Protector Notebook Extension, data is captured and backed up automatically each time a user changes, creates or receives a file. These processes are transparent to the user and do not impact laptop or desktop performance. The data is then stored temporarily in a local repository pending transfer to the network data vault for full backup and restore capabilities. Key features include end-user single-click recovery, encryption and compression techniques.^[17]

Granular Recovery Extensions[edit]

Granular Recovery Extensions are components that sit inside other applications and provide the operator of that application with a way of triggering a large restore and then selecting the individual items that need to be restored without requiring assistance from the backup administrator. For example, the VMware granular recovery extension appears as an extra item in the vSphere console of Vcenter, lets a VMware administrator restore a vmdk file and finally provides an interface for selecting files out of that vmdk file. The SharePoint GRE allows MicrosoftSharePoint administrators to recover a single document, collection or folder directly via the SharePoint GUI. (Granular Recovery for SharePoint 2010 was introduced in version 7.0.)

References[edit]

1. ^'HP Data Protector software : Data sheet'(PDF). HP.com. Retrieved 28 June 2010.
2. ^'HP OpenView OmniBack II versions 3.5 and 4.1 Support Discontinuance Announcement'(PDF) (Press release). HP.com. 31 March 2004. Retrieved 28 June 2010.
3. ^John Cox (3 April 1989). 'Delving into the various modules of Apollo's NCS'. Network World. p. 50. Retrieved 27 August 2011.
4. ^'Business Wire. 'HP Announces New Versions of its Enterprise Storage-Management Applications -- HP OpenView OmniBack II and OmniStorage'' (Press release). Hewlett-Packard. 4 March 1996. Retrieved 28 June 2010.
5. ^'HP porting management apps to Sun'. Network World. 20 July 1992. p. 12. Retrieved 27 August 2011.
6. ^http://reviews.cnet.com/backup-and-recovery/hpov-omniback-ii-for/4507-3682_7-789161.html
7. ^http://ulisse.elettra.trieste.it/services/doc/omniback/ReleaseNote255.pdf
8. ^'HP Data Protector'. Tideway.com. Retrieved 28 June 2010.
9. ^http://www.autonomy.com/work/news/details/huyd0lse
10. ^'Omniback for the System Administrator : Glossary'. Network Technologist.com. Archived from the original on 14 July 2011. Retrieved 28 June 2010.Cite uses deprecated parameter deadurl= (help)
11. ^'HP Data Protector software : Data sheet'(PDF) (Press release). HP.com. Retrieved 28 June 2010.
12. ^Staimer, Marc (25 March 2009). 'Comparing data deduplication products'. TechTarget.com. Retrieved 28 June 2010.
13. ^'HP Data Protector software : Assuring Business Continuity in Virtualised Environments'(PDF). Vmware.com. Retrieved 28 June 2010.
14. ^'Protecting Virtualized Environments from Disaster with HP Data Protector'. InfoWorld.com. 14 April 2010. Archived from the original on 7 June 2010. Retrieved 28 June 2010.Cite uses deprecated parameter deadurl= (help)
15. ^'QuickSpecs: HP Data Protector software'(PDF). HP.com. Retrieved 28 June 2010.
16. ^Raffo, Dave (18 November 2009). 'HP expands laptop and desktop data backup with Data Protector Notebook Extension'. TechTarget.com. Retrieved 28 June 2010.
17. ^Wexler, Steve (25 November 2009). 'HP, HDS Beef Up Back-Up'. Channelinsider.com. Retrieved 28 June 2010.

External links[edit]

Hi,

I've recently installed data protector 9.07 {included recent released patches] and setup backup host[Vepa agent] on 2 physical servers with Store CoFC.

I've seen strange data flow behaviour between [Datastore =<=FC>=>IP=> Storeonce CoFC, might due to configuration error by me :P.

I've installed 2 backup host {physical servers] with VEPA agents and also configured both backup hosts GATEWAY [FC] in Cell manager GUI.

configuration:

2 physical backup hosts {BKHost-A, BKHost-B configured with VEPA {+ configured as FC GATEWAY {CoFC} - in GUI }

+ datastore lun's are presented to both BK hosts.

my question is:

Can i have more than 1 VEPA agents in my environment ? if yes - how i can use them ? by adding gateway or by adding some configuration?

I have 2 situations:

situation 1 : Vepa agents are installed on both BkHosts {A,B}. Configured in Cell manager gui as FC gateway with StoreOnce CoFC. in this scanerio , i start to backup VM and backup is succesful and transfer through FC gateway {BkHost-B} to StoreOnce CoFC. no traffic seen on ethernet ports. - OK

It seems backup was done through BKHost-B FC gateway to COFC

Situation 2: i removed BKHosts-B FC gateway and run the same backup job. backup job started but i've seen the traffic flow on Ethernet ports from BKHosts-B {Send} to BKHost-A {Recv.}

Question is here , why traffic is flowing between BKHosts on Ethernet ports {10G} ? as per vepa agent configuration, it should select FC path to CoFC {Catalyst store}

one more question : I've also noticed that in SAN mode Backup Speed .... 97.95 MB/s - It seems some issue with FC configuration or any other reason to have less bandwidth ? or just it is standard

Please have a look on below logs {situation-2}

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:26:37 AM
Backup session 2016/07/13-4 started.

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:26:38 AM
OB2BAR application on 'BKHost-B' successfully started.

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:14 AM
Resolving objects for backup on vCenter 'Vmware_Vcenter' ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:16 AM
Add Virtual Machine to the backup ..
Name: Virtual_Machine_Client
Path: /SL/vm/Virtual_Machine_Client
InstanceUUID: 503f9def-66ae-e0cf-0652-71853de18d00

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:19 AM
Virtual Machine 'Virtual_Machine_Client': Locking vMotion ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:20 AM
Creating folder /var/opt/omni/tmp/5d76139f-3ec6-48e6-8562-ccf785654aa3 ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:21 AM
Virtual Machine 'Virtual_Machine_Client': Backing up configuration file Virtual_Machine_client.vmx ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:23 AM
Virtual Machine 'Virtual_Machine_Client': Creating snapshot ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:26:29 AM
Virtual Machine 'Virtual_Machine_Client': Getting Changed Blocks for disk scsi0:0.

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:29:49 AM
Virtual Machine 'Virtual_Machine_Client' (UUID '503f9def-66ae-e0cf-0652-71853de18d00', Disk 'scsi0:0'): Starting full backup ..

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:30:21 AM
STARTING Media Agent 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]'

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:30:21 AM
Loading medium from slot COFC-node1FCS1/8c63f60a_5785ee07_576c_0019 to device StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:30:21 AM
Using interface path: COFC-node1FCS1/8c63f60a_5785ee07_576c_0019

Driver downloads for windows 7. At times this behavior was intermittent where I might get one label to print OK and at other times no labels would print at all. I spent countless hours playing around with the Smart Label software application but one of my problems ended up not having anything to do with the printer or the software but was an issue with my PC. In my case, the label would start to print but then stop and I'd have to manually flush the queue. Seiko Smart Label Printers 100 and 200 On Windows 10 Knowledge Is Power Getting Older Seiko Smart Label Printers To Work On Windows 10 If you have an older model 100 or 200 Smart Label Printer by Seiko you may run into problems when you try to get them to work on Windows 10.

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:29:51 AM
Starting OB2BAR Backup: Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00%2F6000C297-c07e-f252-e38e-ad994ded8a38 'VEAgentDisk'

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:29:51 AM
Virtual Machine 'Virtual_Machine_Client': Backing up ..
Disk: scsi0:0
Transport method: SAN
Disk buffer: 256 MB

Hp Data Protector 9.0 Patches Download

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:29:51 AM
Virtual Machine 'Virtual_Machine_Client': Disk 'scsi0:0' datastore information
Datastore: ESXi_Datastore.43.43
Datastore type: VMFS
Datastore Storage WWN: 60002ac0000000000000002b0001a3b1

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:32:39 AM

Server-side Deduplication Statistics for Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00%2F6000C297-c07e-f252-e38e-ad994ded8a38 'VEAgentDisk'.
Using device: 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]@BKHost-A':
Mbytes Total: ......... 15017 MB
Mbytes Written to Disk: .... 46 MB
Deduplication Ratio: ..... 326.4 : 1

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:32:17 AM
Backup Profile:

Run Time ...... 0:02:26
Backup Speed .... 102.65 MB/s

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:32:17 AM
Completed OB2BAR Backup: Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00%2F6000C297-c07e-f252-e38e-ad994ded8a38 'VEAgentDisk'

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:32:22 AM
Starting OB2BAR Backup: Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00 'VEAgent'

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:32:55 AM
Unloading medium to slot COFC-node1FCS1/8c63f60a_5785ee07_576c_0019 from device StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:32:55 AM
Loading medium from slot COFC-node1FCS1/8c63f60a_5785eea1_576c_001b to device StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:32:56 AM
Using interface path: COFC-node1FCS1/8c63f60a_5785eea1_576c_001b

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:32:51 AM

Server-side Deduplication Statistics for Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00 'VEAgent'.
Using device: 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]@BKHost-A':
Mbytes Total: ......... 1 MB
Mbytes Written to Disk: .... 1 MB
Deduplication Ratio: ..... 1.0 : 1

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:32:28 AM
Backup Profile:

Run Time ...... 0:00:06
Backup Speed .... 0.00 MB/s

[Normal] From: OB2BAR_VEPA_BAR@BKHost-B '/SL' Time: 7/13/2016 10:32:28 AM
Completed OB2BAR Backup: Vmware_Vcenter:/4/Vmware_Vcenter%2F503f9def-66ae-e0cf-0652-71853de18d00 'VEAgent'

Windows 10 Patches Download

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:32:29 AM
Virtual Machine 'Virtual_Machine_Client': Removing snapshot ..

[Normal] From: VEPALIB_VMWARE@BKHost-B ' Time: 07/13/2016 10:32:33 AM
Virtual Machine 'Virtual_Machine_Client': Unlocking vMotion ..

Hp Data Protector 9

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:33:08 AM
OB2BAR application on 'BKHost-B' disconnected.

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:33:15 AM
Unloading medium to slot COFC-node1FCS1/8c63f60a_5785eea1_576c_001b from device StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]

[Normal] From: BMA@BKHost-A 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]' Time: 7/13/2016 10:33:15 AM
COMPLETED Media Agent 'StoreOnce_gw1_BKHost-A [GW 1488:0:15106138014348667170]'

[Normal] From: BSM@Cell_Manager 'Vmware_Vcenter' Time: 7/13/2016 10:33:09 AM

Backup Statistics:
Session Queuing Time (hours) 0.00
-------------------------------------------
Completed Disk Agents .... 2
Failed Disk Agents ...... 0
Aborted Disk Agents ..... 0
-------------------------------------------
Disk Agents Total ...... 2
Completed Media Agents .... 1
Failed Media Agents ..... 0
Aborted Media Agents ..... 0
-------------------------------------------
Media Agents Total ..... 1
Throttled Gateways ...... 0
Gateways Total ........ 1
Overall Deduplication Ratio . 319.5 : 1
Mbytes Total ......... 15017 MB
Used Media Total ....... 2
Disk Agent Errors Total ... 0

Hp Data Protector 9.0 Manual

Session completed successfully!

Data Protector 9.0 Patches

Many Thanks,

Data Protector 9 Patches Download

DPx
